Falling Dart Impact Tester

STL-A/D
Focusing on packaging and material testing technology, we are committed to quality control in industries such as healthcare, pharmaceuticals, food, packaging, textiles, and new materials. Our products are widely used in enterprises, testing institutions, universities, and research institutes.
  • Description
  • Applications
  • Standard
  • Features
  • Parameter
  • Configuration
  • Video
  • PDF Download
    • Commodity name: Falling Dart Impact Tester
    • Commodity ID: STL-A/D

    STL-A/D

    Function
    It is used to determine the impact resistance of plastic film or sheet. The falling dart falls freely at a given height to impact the specimen. The impact mass and energy of 50% sample were measured.


    Standards

    GB 9639, ASTM D1709, JIS K7124


    Characteristics
    ●Comply with national and international standards and correct errors in national and international standards.
    Test methods: A method, A + B double method.
    The lamp for observation is convenient for sample inspection.
    The test process is intelligent and efficient.
    Microcomputer processing of test data.
    The sample is pneumatically clamped and released to reduce the test error and test time.
    The test process does not need manual drawing and marking, and the data parameter system is displayed on LCD.
    The test data system can automatically identify and calculate without manual intervention.
    Testing automatically completed, results displayed in multiple units, exported by micro printer.



    Specification

    Name

    STL-A

    STL-D

    Test mode

    A

    A, B

    Range

    50~2000g

    Precision

    0.1g

    Clamping mode

    Pneumatic

    Sample size

    >150mm×150mm

    Size (L×B×H )

    670mm×400mm×1300mm

    670mm×400mm×2100mm

    Net weight

    70Kg

    80Kg

    Selt-supply

    Gas resource



    Configuration

    Principle machine, a set of weights for method A, a set of weights for method B(only for STL-D type machine).

  •

  •

  •

  •
